ASL V32BIS Delta Plus CLI (LAN) 305 Modem via telephone network

Dial Up modem compatible communications data rates up to 14400bps
Industry standard 25 way D-type socket interface
Flexible power supply of 5V to 15VDC
Standby mode with current drain of < 30mA
Typical average operating power of < 40mA
Plug in compatibility with other Delta Plus and many other modems
Dimensionally compact and cost effective
Stores 8 specific CLI numbers and uses ‘Wildcard’ numbering
Supports auto-dial, auto answer and no ring answer on CLI
NVRAM holds configuration parameter information

Enquire Now

Product Details

The Delta Plus LAN Modem allows access to remote data via the public telephone networks. The flexible input power supply requirements further enhance the ease of use.

Product Specification

Approvals: The product conforms to: EN41003/EN60950, R&TTE directive 99/5/EC EMC Directive 89/336/EEC & Low Voltage Directive 73/23/EEC
Auto dial/answer: Under ‘AT’ command control. Auto answer with Call Indicate
Control of functions: By ‘AT’ compatible command subset
CLI Support: Caller Line Identification (CLI ) support will be available soon - upgradeable on line
Data rates & standards: V22 (1200bps), V22bis (2400bps), V32 (9600bps), V32bis (14400bps)
Data port: RS232 (V24/28) asynchronous serial port supporting RXD, TXD, DCD, DTR, RTS and CTS
Data port connector: Integral 25 way ‘D’ socket. Standard pin-out with power on pin 7 – ve, pin 9 and 15 + ve
Enclosure: Custom moulded plastic housing, size - 61x57x24mm.
Environmental conditions: -20 to +55°C operating; –20 to +70°C storage. Humidity 0-95% non-condensing
Power supply: Powered from the host data port. +5V to +15 V dc Also power socket for optional external power supply Delta Plus CLI Modem at 9V, 29mA standby, 39mA communicating
Remote configuration: By the use of Hyper Terminal or any suitable terminal emulation package for access
Weight: 55 grams
